TEAMGROUP MP33 M2 512GB
| Model | MP33 M.2 PCIe SSD | |||
| Interface | PCIe 3.0 x4 with NVMe | |||
| Capacity | 128GB / 256GB / 512GB / 1TB / 2TB[2] | |||
| Voltage | DC +3.3V | |||
| Operation Temperature | 0˚C ~ 70˚C | |||
| Storage Temperature | -40˚C ~ 85˚C | |||
| DRAM Cache | NO | |||
| Terabyte Written | 128GB – 75TBW 256GB – 150TBW 512GB – 350TBW 1TB – 600TBW 2TB – 1000TBW[3] |
|||
| Performance | Crystal Disk Mark: 128GB Read/Write: up to 1,500/500 MB/s 256GB Read/Write: up to 1,600/1,000 MB/s 512GB Read/Write: up to 1,700/1,400 MB/s 1TB Read/Write: up to 1,800/1,500 MB/s 2TB Read/Write: up to 1,800/1,500 MB/s[1]IOPS: 128GB Read/Write: 90K/100K IOPS Max 256GB Read/Write: 160K/200K IOPS Max 512GB Read/Write: 220K/200K IOPS Max 1TB Read/Write: 220K/200K IOPS Max 2TB Read/Write: 220K/200K IOPS Max[1] |
|||
| Weight | 6g | |||
| Dimensions | 80(L) x 22(W) x 3.8(H) mm | |||
| Humidity | RH 90% under 40°C (operational) | |||
| Vibration | 80Hz~2,000Hz/20G | |||
| Shock | 1,500G/0.5ms | |||
| MTBF | 1,500,000 hours | |||
| Operating System | System Requirements:
|
|||
